Deep Hole Water Well Air Compressor – KSZJ Series
Features
Product Details
KSZJ Series Parameters
| Model | Exhaust pressure(Mpa) |
Exhaust volume (m³/min) |
Motor power(KW) | Exhaust connection | Weight(kg) | Dimension(mm) |
| KSZJ-15/15 | 1.5 | 15 | Yuchai:190HP | G2x1,G3/4x1 | 2100 | 2600x1520x1800 |
| KSZJ-18/17A | 1.7 | 18 | Yuchai:220HP | G2x1,G3/4x1 | 2400 | 3000x1520x2000 |
| KSZJ-18/18 | 1.8 | 18 | Yuchai:260HP | G2x1,G3/4x1 | 2700 | 3000x1800x2000 |
| KSZJ-29/23G | 2.3 | 29 | Yuchai:400HP | G2x1,G3/4x1 | 4050 | 3500x1950x2030 |
| KSZJ-29/23-32/17 | 1.7-2.3 | 29-32 | Yuchai:400HP | G2x1,G3/4x1 | 4050 | 3500x1950x2030 |
| KSZJ-35/30-38/25 | 2.5-3.0 | 35-38 | Cummins:550HP | G2x1,G3/4x1 | 5400 | 3500x2160x2500 |
Applications
Mining
Water Conservancy Project
Road/Railway Construction
Shipbuilding
Geothermal
In order to adapt to different working conditions and environments, our deep hole water well air compressors have dual pressure sections. This unique feature allows the compressor to adapt seamlessly, ensuring optimal performance regardless of the task at hand. From high pressure requirements to low pressure applications, this compressor has you covered.
Extreme weather conditions are no match for our deep bore water well air compressors. This compressor is designed to withstand high temperatures and operate fearlessly in even the harshest climates. Whether it's sweltering heat or freezing cold, you can rely on our air compressors to maintain peak performance, ensuring uninterrupted operation year-round.
With its superior power, adaptability and resiliency, it goes beyond traditional compressors to deliver outstanding results every time. Whether you want to dig a deep well, build a sturdy building, or harness geothermal energy, our air compressors are the tool you need.
