Scroll Air Compressor – OX Series
Features
Product Details
OX Series Parameters
| Model | Exhaust volume (m3/min) |
Exhaust pressure (Mpa) |
Supply air temperature (℃) |
Air supply oil content(ppm) | Motor Power (kw/hp) |
Noise dB(A) |
Weight (kg) |
L*W*H (mm) |
Linkage and start mode |
Standard configuration |
Remark |
| OX-0.3/8 | 0.3 | 0.8 | Ambient Temperature +50 |
≤3，Slightly Oily | 2.2/3 | （57-63）±3 | 85 | 780*390*650 | Direct Start, Direct Connection |
220V single phase, without tank | without aftercooling |
| OXX-0.3/8 | 130 | 950*500*1050 | 220V single phase, with tank 75L | ||||||||
| OXX-0.66/8 | 0.66 | 0.8 | 4.5/6 | （57-63）±3 | 185 | 920*430*1025 | Direct Start, Direct Connection |
With tank 75L | |||
| OX-0.66/8 | 140 | 868*430*690 | without tank | ||||||||
| OX-0.8/10 | 0.8 | 1 | 7.5/10 | （57-63）±3 | 212 | 925*540*820 | Direct Start, Direct Connection |
without tank | |||
| OX-1.1/8 | 1.1 | 0.8 | |||||||||
| OX-1.3/10 | 1.3 | 1 | 11/15 | （57-63）±3 | 363 | 1080*640*880 | Y-∆ Start, Direct Connection |
without tank | |||
| OX-1.6/8 | 1.6 | 0.8 | |||||||||
| OX1.6/10 | 1.6 | 1 | 15/20 | （57-63）±3 | 428 | 1130*690*915 | Direct Start, Direct Connection |
without tank | |||
| OX-2.2/8 | 2.2 | 0.8 | |||||||||
| OX-2.6/10 | 2.6 | 1 | 22/30 | （57-63）±3 | 630 | 1320*810*1000 | Y-∆ Start, Direct Connection |
without tank | |||
| OX-3.2/8 | 3.2 | 0.8 | |||||||||
| OXT-1.1/8 | 1.1 | 0.8 | 7.5/10 | （57-63）±3 | 218 | 835*540*870 | Direct Start, Direct Connection |
without tank | |||
| OXT-2.2/8 | 2.2 | 0.8 | 15/20 | 418 | 1072*680*955 |
OX Series - two-stage medium pressure micro-oil Parameters
| Model | EOX-1.2/30 | EOGFD-4.0/30 | EOGFD-6.0/30 | |
| Air capacity（m3/min） | 1.2 | 4 | 6 | |
| Working Pressure(MPa) | 3 | |||
| Ambient temperature (℃) | 2~40 | |||
| Compression method | Two Levels | |||
| Noise dB(A) | 85±3 | 85±3 | 87±3 | |
| Air supply oil content（ppm） | ≤3 slightly oily | |||
| Motor | Rotating speed (r/min) |
2915 | 2965 | 2970 |
| Power (KW/HP) |
15/20 | 37/50 | 55/75 | |
| Start method | Parallel star-delta start, direct connection |
Star-delta start, direct connection | ||
| Supply Voltage /Frequency V/Hz |
380/50/3Φ | |||
| L x W x H (mm) | 1350×850×1105 | 1980×950×1485 | 2240×950×1485 | |
| Weight (kg) | 558 | 1600 | 1880 | |
OX Series - medium pressure Parameters
| Model | OXXA-1.1/16 | OXXA-1.28/16 | OXXA-1.2/18 | OX-1.1/16 | OX-1.28/16 | |
| Air capacity(m3/min) | 1.1 | 1.28 | 1.2 | 1.1 | 1.28 | |
| Working Pressure(MPa) | 1.6 | 1.6 | 1.8 | 1.6 | 1.6 | |
| Ambient temperature (℃) | 3~ Ambient temperature | Ambient temperature +15 (fan start) | ||||
| Motor | Rotating speed（r/min） | 2930 | ||||
| Power(KW/HP) | 11/15 | 15/20 | 15/20 | 11/15 | 15/20 | |
| Start method | direct start, direct connection | |||||
| Voltage V Frequency Hz/PHASE |
380/50/3 Φ | |||||
| Air supply oil content(ppm) | ≤3 | |||||
| Air storage tank volume (L) | 300 | |||||
| Air dryer power supply (Voltage V Frequency Hz/PHASE) |
220/50/1 Φ | |||||
| Oil content of aftertreatment air supply(ppm) | ≤0.01 | |||||
| Dust particle size in post-treatment supply air(μm) | ≤0.01 | |||||
| Aftertreatment air supply pressure dew point(℃) |
3〜10 | |||||
| L×W×H(mm) | 1750x 720x 1510 | 1060 x 680 x 1000 | ||||
| Weight(kg) | 550 | 340 | ||||
| The standard configuration | With air dryer, 3-stage filters, gas-water separator, 300L tank | Single unit | ||||
Applications
Medicine
Packing
Chemical Industry
Food
